ABC - 2500 Mm X 280CH Hydraulic Cylindrical Gtinding Machine
4050000 INR/Unit
Product Details:
- Product Type ABC - 2500 Mm X 280CH Hydraulic Cylindrical Gtinding Machine
- General Use Industrial
- Automatic No
- Dimension (L*W*H) 650 mm X 65 mm X 254 mm Millimeter (mm)
- Feature High Efficiency
- Color Green
- Warranty Yes
- Click to View more
X
ABC - 2500 Mm X 280CH Hydraulic Cylindrical Gtinding Machine Price And Quantity
- 1 Unit
- 4050000 INR/Unit
ABC - 2500 Mm X 280CH Hydraulic Cylindrical Gtinding Machine Product Specifications
- No
- 650 mm X 65 mm X 254 mm Millimeter (mm)
- Green
- Industrial
- Yes
- High Efficiency
- ABC - 2500 Mm X 280CH Hydraulic Cylindrical Gtinding Machine
ABC - 2500 Mm X 280CH Hydraulic Cylindrical Gtinding Machine Trade Information
- 45-60 Days
Product Description
ABC - 2500 Mm X 280CH Hydraulic Cylindrical Gtinding Machine is a precision-engineered tool designed to meet the demanding requirements of modern manufacturing. This machine boasts a robust construction, incorporating advanced hydraulic technology for precise control over grinding operations. Its generous work envelope of 2500 mm length and 280 mm diameter ensures versatility in handling various workpieces. Ideal for industrial applications, this ABC - 2500 Mm X 280CH Hydraulic Cylindrical Gtinding Machine offers efficiency and accuracy, making it an indispensable asset for machining workshops.
| Type of Grinding Machine | Cylindrical Grinding Machine |
| Maximum Swing Over Bed | 559 mm |
| Distance between Centers | 2500 mm |
| Grinding Material | Metal |
| Work Head Swivel | 30 Deg |
| Automation Grade | Semi-Automatic |
| Grinding Wheel Diameter(mm) | 650 mm X 65 mm X 254 mm |
| Work Head Center | 280 mm |
| Max. Grinding Length (mm) | 2500 mm |
| Dwell at reversals | 20 sec |
| Max. Grinding Wheel Speed (rpm) | 1400 rpm |
| Job Material | Metal |
| Grinding Wheel/Spindle Motor Power (HP/W) | 15 hp |
| Tail Stock Center | 280 mm |
| X-axis Feed Speed (m/min) | 0.1 to 0.4 mtr. / min |
| Z-axis Feed Speed (m/min) | 2000 mm / per min |
| Max. Table Load (kg) | 600 kg |
| Country of Origin | Made in India |
